Van Norman Flywheel Grinders

FG10000

Heavy production flywheel grinder with 10 HP motor and maximum head clearance

The FG10000 is the heavy production version of the Van Norman line — built for the shop that grinds flywheels all day, every day. A 10 HP grinding motor, oversized 5.5-inch column, and 10.5 inches of vertical head clearance — the most in the industry — make this the right machine for the most demanding truck and heavy duty applications. Same fast, simple setup as the FG5000. Same no-deflection table. More power, more clearance, more capacity.

• One-piece 480 lb base casting — the heaviest and most rugged in the industry
• Exclusive cast-in table support: NO DEFLECTION, EVER — unlimited grinding pressure possible
• Oversized 5.5" column with massive thick wall — maximum rigidity for heavy production
• 10.5" vertical head travel and clearance — the most clearance in the industry
• Optomatic constant oiler — automatic lubrication to column and table support
• Direct table drive — no chains or belts to adjust or replace, consistent torque
• Double cam head swivel lock — positive head lock, lubricated for easy swiveling
• No thrust bearings or anti-friction materials requiring field service
• Setup in under one minute — no indicating, no guessing, no scratch test
• Optional PowerHead (Power Column) available — eliminates manual head movement
• Optional AutoGrind TM — automatically grinds flywheel to pre-set depth
• Optional HD Truck Brake Rotor Kit — opens commercial vehicle rotor repair market
• Made in Cedar Rapids, Iowa by American craftsmen
